In the world of woodworking, the table saw is an essential and versatile tool. Among the various components that contribute to its functionality, the table saw blade is of utmost importance. Different types of table saw blades are designed for specific tasks, and one such specialized blade is the one used for resawing. Resawing is a technique that allows woodworkers to create thinner and wider boards from a single piece of lumber. It is a valuable skill in furniture making, cabinetry, and other woodworking projects where specific thicknesses and widths are required. Understanding the table saw blade for resawing is crucial for achieving accurate and high – quality results in woodworking.
The Basics of Resawing
Resawing is the process of cutting a board along its thickness, essentially splitting it into thinner slabs. This is in contrast to ripping, which involves cutting a board along its length to create narrower pieces, or cross – cutting, which is cutting a board across its width to a specific length. Resawing allows woodworkers to access the beautiful and often unique grain patterns that run through a piece of wood, and it also provides more flexibility in terms of board dimensions.
For example, if you have a wide piece of hardwood and you want to make a tabletop with a very thin edge or a drawer front with a specific grain pattern, resawing can help you achieve your goals. By resawing the wood, you can create thin slabs that can be planed and finished to your desired specifications.
Features of a Table Saw Blade for Resawing
Tooth Count and Configuration
The number of teeth on a table saw blade for resawing is an important factor. Typically, resaw blades have a lower tooth count compared to blades used for ripping or cross – cutting. A lower tooth count, usually in the range of 24 to 32 teeth, is preferred for resawing. This is because fewer teeth mean larger gullets between the teeth. Larger gullets can hold more sawdust and chips, which helps in maintaining a smooth cutting process. When cutting thick wood during resawing, a large amount of material needs to be removed. If the gullets are too small, as in high – tooth – count blades, they can quickly become clogged, leading to poor cutting performance, excessive heat buildup, and potentially damaging the blade or the wood.
The tooth configuration on a resaw blade is often a combination of alternate – top – bevel (ATB) and raker teeth. The ATB teeth are designed to cut cleanly and provide a smooth finish on the surface of the board. The raker teeth, which are usually set at a different angle and have a different shape, are responsible for clearing the chips from the cut. The raker teeth can be either a standard raker or a skip – tooth raker. A standard raker cuts and cleans the chips, while a skip – tooth raker has more space between the teeth, allowing for even better chip clearance, especially when cutting wet or green wood.
Blade Width and Diameter
The width of a table saw blade for resawing is generally wider than standard blades. A wider blade provides more stability during the cutting process, which is crucial when making deep cuts in thick wood. Wider blades are less likely to deflect or wobble, ensuring a straight and accurate cut. Common blade widths for resawing range from 1/2 inch to 1 inch, although some specialty blades can be even wider.
The diameter of the blade also plays a role in resawing. Table saws typically come with blades in various diameters, such as 10 inches, 12 inches, or 14 inches. Larger – diameter blades can make deeper cuts in one pass, which can be an advantage when resawing thick wood. However, it’s important to note that the depth of cut is also limited by the design of the table saw and the height of the blade arbor. For most standard table saws, the maximum depth of cut is around 3 inches, regardless of the blade diameter. But using a larger – diameter blade can still give you more control and a cleaner cut when resawing.
Blade Material
The material used to make a table saw blade for resawing is another important consideration. High – speed steel (HSS) is a common material for resaw blades. HSS blades are relatively inexpensive and can withstand high cutting speeds. They are durable and can maintain a sharp edge for an extended period, making them suitable for general resawing tasks.
Another popular material is carbide – tipped. Carbide – tipped blades are more expensive than HSS blades but offer several advantages. Carbide is a very hard material, which means that the cutting edges of the teeth can stay sharp for a longer time. This results in cleaner cuts and less frequent blade sharpening or replacement. Additionally, carbide – tipped blades can handle hardwoods and other tough materials more easily, making them a great choice for professional woodworkers or those who work with difficult – to – cut woods on a regular basis.
How a Resaw Blade Works
When using a table saw blade for resawing, the blade rotates at high speed, usually between 3,000 and 5,000 revolutions per minute (RPM), depending on the table saw’s motor. As the wood is fed into the blade, the teeth on the blade engage with the wood and start to cut through it.
The ATB teeth first make contact with the wood and begin to cut the surface. They shear the fibers of the wood, creating a relatively smooth cut. As the blade cuts deeper into the wood, the larger gullets between the teeth start to collect the sawdust and chips. The raker teeth then come into play. They not only continue to cut the wood but also help in expelling the chips from the cut. The large gullets of the raker teeth act as a reservoir for the chips, preventing them from clogging the blade and ensuring a smooth cutting process.
The width and diameter of the blade provide stability during the cut. A wider blade resists the tendency to deflect, keeping the cut straight. A larger – diameter blade can make a deeper initial cut, which helps in starting the resawing process more easily. As the cut progresses, the blade continues to remove material layer by layer until the desired thickness is achieved.
Choosing the Right Resaw Blade
Considering the Type of Wood
The type of wood you are working with is a major factor in choosing the right resaw blade. Different woods have different densities, hardnesses, and grain patterns. For example, softwoods such as pine are generally easier to cut than hardwoods like oak or maple. If you are resawing softwoods, a lower – cost HSS blade may be sufficient, as the softer wood is less likely to damage the blade.
However, when working with hardwoods, a carbide – tipped blade is often a better choice. Hardwoods are denser and more abrasive, and they can quickly dull the teeth of an HSS blade. Carbide – tipped blades are more resistant to abrasion and can maintain their sharp cutting edges for a longer time, resulting in cleaner cuts and less downtime for blade maintenance.
The Thickness of the Wood
The thickness of the wood you plan to resaw also affects the choice of blade. For thicker boards, a blade with a larger diameter and a wider width may be necessary. A larger – diameter blade can make a deeper initial cut, which reduces the number of passes required to reach the desired thickness. A wider blade provides more stability, which is crucial when cutting thick wood to prevent the blade from deflecting and causing an uneven cut.
If you are resawing relatively thin boards, you may be able to use a smaller – diameter blade with a slightly narrower width. However, it’s still important to choose a blade with a low tooth count and appropriate tooth configuration to ensure a clean and efficient cut.
The Desired Quality of the Cut
The quality of the cut you want to achieve is also an important consideration. If you need a very smooth and precise cut, a carbide – tipped blade with a fine tooth configuration may be the best option. The fine teeth can create a smoother surface finish, which is important for applications where the finished appearance of the wood is a priority, such as in fine furniture making.
On the other hand, if you are resawing wood for rough construction or where a less – than – perfect finish is acceptable, a more affordable HSS blade with a coarser tooth configuration may be sufficient. However, keep in mind that even for rough projects, a blade with the appropriate characteristics for resawing will still result in a more efficient and safer cutting process.
Using a Table Saw Blade for Resawing
Setting Up the Table Saw
Before using a resaw blade, it’s essential to properly set up the table saw. First, ensure that the blade is installed correctly and securely. Check that the blade is centered on the arbor and that the arbor nut is tightened to the manufacturer’s specifications.
Next, adjust the blade height. The blade should be set just high enough to cut through the wood without exposing too much of the blade above the wood. This reduces the risk of kickback and also helps in keeping the cut more stable. A general rule of thumb is to set the blade height to about 1/8 to 1/4 inch above the thickness of the wood being cut.
Then, adjust the fence. The fence is used to guide the wood as it is fed into the blade. Make sure the fence is parallel to the blade. This can be done using a dial indicator or a feeler gauge. A parallel fence ensures a straight cut. You may also want to use a resaw guide or a featherboard to help keep the wood stable and prevent it from moving during the cut.
Feeding the Wood
Feeding the wood into the blade at a consistent and controlled rate is crucial for a successful resawing operation. Push the wood slowly and steadily through the blade, using a push stick or a push block to keep your hands a safe distance from the blade. Do not force the wood through the blade; let the blade do the work. Forcing the wood can cause the blade to bind, resulting in kickback or a poor – quality cut.
If you are resawing a long board, it may be helpful to have an assistant to help you guide the board through the blade. This will ensure that the board stays straight and reduces the risk of accidents.
Monitoring the Cut
During the resawing process, it’s important to monitor the cut closely. Watch for signs of blade binding, such as the blade slowing down or making a unusual noise. If you notice any of these signs, stop the saw immediately and check the setup. You may need to adjust the blade height, the fence, or the way the wood is being fed into the blade.
Also, keep an eye on the chips being removed. If the gullets of the blade start to fill up with chips, it can cause the blade to overheat and affect the quality of the cut. In such cases, you may need to pause the cutting process and clear the chips from the blade.
Maintenance of a Resaw Blade
Cleaning
After each use, it’s important to clean the resaw blade to remove any sawdust and debris. You can use a soft brush or compressed air to clean the blade. This will help prevent the buildup of sawdust, which can affect the blade’s performance and cause premature wear.
Sharpening
Over time, the teeth of the resaw blade will become dull. When this happens, the blade will not cut as efficiently, and the quality of the cut will deteriorate. If you have an HSS blade, you can sharpen it using a bench grinder or a specialized blade sharpener. However, sharpening HSS blades requires some skill and knowledge to ensure that the teeth are sharpened correctly.
Carbide – tipped blades are more difficult to sharpen, and in most cases, it’s recommended to have them professionally sharpened. Some manufacturers offer sharpening services, or you can take the blade to a local tool and die shop that specializes in blade sharpening.
Inspection
Regularly inspect the blade for any signs of damage, such as cracked or chipped teeth. If you notice any damage, the blade should be replaced immediately. Continuing to use a damaged blade can be dangerous and can also result in poor – quality cuts.
Safety Considerations
Blade Guards
Always use the blade guard provided with your table saw when using a resaw blade. The blade guard helps to protect you from accidental contact with the blade. It also helps to contain any flying debris and can improve the safety and efficiency of the cutting process.
Personal Protective Equipment
Wear appropriate personal protective equipment (PPE) when using a table saw with a resaw blade. This includes safety glasses to protect your eyes from flying sawdust and debris, hearing protection to protect your ears from the loud noise of the saw, and a dust mask to protect your lungs from inhaling sawdust.
Kickback Prevention
Kickback is a major safety hazard when using a table saw. To prevent kickback, make sure the blade is installed correctly, the wood is fed into the blade at a consistent rate, and the fence is properly adjusted. You can also use anti – kickback devices such as riving knives or splitters, which are designed to prevent the wood from pinching the blade and causing it to kick back.
Conclusion
In conclusion, a table saw blade for resawing is a specialized tool that plays a crucial role in woodworking. Understanding the features, how it works, and how to choose, use, and maintain it is essential for achieving accurate and high – quality results in resawing projects. The tooth count, configuration, width, and diameter of the blade all contribute to its performance, and choosing the right blade for the type of wood, desired cut quality, and thickness is key to a successful resawing operation.
